| Name | Value |
|---|---|
| Product Status | Active |
| Type | Isolated Module, Conformal Coated |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 14.4V |
| Voltage - Input (Max) | 154V |
| Voltage - Output 1 | 15V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 3.3A |
| Power (Watts) | 50 W |
| Voltage - Isolation | 3 kV |
| Applications | ITE (Commercial) |
| Features | Baseplate, Remote On/Off |
| Operating Temperature | -40°C ~ 105°C (With Derating) |
| Efficiency | 90% |
| Mounting Type | Through Hole |
| Package / Case | Quarter Brick |
| Size / Dimension | 2.30" L x 1.45" W x 0.59" H (58.4mm x 36.8mm x 15.0mm) |
| Supplier Device Package | Quarter Brick |
| Control Features | Enable, Active Low |
| Approval Agency | CSA, UL |
| Standard Number | 62368-1 |
