| Name | Value |
|---|---|
| Product Status | Obsolete |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 20 V |
| Current - Continuous Drain (Id) @ 25°C | 1.4A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 1.8V, 2.5V |
| Rds On (Max) @ Id, Vgs | 160mOhm @ 1.4A, 2.5V |
| Vgs(th) (Max) @ Id | 0.95V @ 3.7µA |
| Gate Charge (Qg) (Max) @ Vgs | 0.6 nC @ 2.5 V |
| Vgs (Max) | ±8V |
| Input Capacitance (Ciss) (Max) @ Vds | 180 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | 500mW (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PG-SOT363-6 |
| Package / Case | 6-VSSOP, SC-88, SOT-363 |
