| Name | Value |
|---|---|
| Product Status | Discontinued at Digi-Key |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 240 V |
| Current - Continuous Drain (Id) @ 25°C | 350mA (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 0V, 10V |
| Rds On (Max) @ Id, Vgs | 6Ohm @ 350mA, 10V |
| Vgs(th) (Max) @ Id | 1V @ 108µA |
| Gate Charge (Qg) (Max) @ Vgs | 5.7 nC @ 5 V |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 108 pF @ 25 V |
| FET Feature | Depletion Mode |
| Power Dissipation (Max) | 1.8W (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PG-SOT223-4 |
| Package / Case | TO-261-4, TO-261AA |
