| Name | Value |
|---|---|
| Product Status | Active |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 25 V |
| Current - Continuous Drain (Id) @ 25°C | 40A (Ta), 214A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | - |
| Rds On (Max) @ Id, Vgs | 1.1mOhm @ 40A, 10V |
| Vgs(th) (Max) @ Id | 2.1V @ 100µA |
| Gate Charge (Qg) (Max) @ Vgs | 68 nC @ 4.5 V |
| Vgs (Max) | ±16V |
| Input Capacitance (Ciss) (Max) @ Vds | 5630 pF @ 13 V |
| FET Feature | Schottky Diode (Body) |
| Power Dissipation (Max) | 2.8W (Ta), 78W (Tc) |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | DirectFET™ Isometric MX |
| Package / Case | DirectFET™ Isometric MX |
