| Name | Value |
|---|---|
| Product Status | Obsolete |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 12 V |
| Current - Continuous Drain (Id) @ 25°C | 5.5A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 2.5V, 4.5V |
| Rds On (Max) @ Id, Vgs | 42mOhm @ 5.5A, 4.5V |
| Vgs(th) (Max) @ Id | 600mV @ 250µA (Min) |
| Gate Charge (Qg) (Max) @ Vgs | 33 nC @ 5 V |
| Vgs (Max) | ±12V |
| Input Capacitance (Ciss) (Max) @ Vds | 1820 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | 1.7W (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | Micro6™(TSOP-6) |
| Package / Case | SOT-23-6 |
