| Name | Value |
|---|---|
| Product Status | Obsolete |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 50 V |
| Current - Continuous Drain (Id) @ 25°C | 50mA (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 2.5V |
| Rds On (Max) @ Id, Vgs | 50Ohm @ 10mA, 2.5V |
| Vgs(th) (Max) @ Id | 1.1V @ 100µA |
| Gate Charge (Qg) (Max) @ Vgs | - |
| Vgs (Max) | 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 4.5 pF @ 5 V |
| FET Feature | - |
| Power Dissipation (Max) | 150mW (Ta) |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | SMini3-F2 |
| Package / Case | SC-85 |
