| Name | Value |
|---|---|
| Product Status | Not For New Designs |
| Number of Channels | 1 |
| Voltage - Isolation | 3750Vrms |
| Current Transfer Ratio (Min) | 20% @ 16mA |
| Current Transfer Ratio (Max) | 35% @ 16mA |
| Turn On / Turn Off Time (Typ) | 500ns, 600ns |
| Rise / Fall Time (Typ) | - |
| Input Type | DC |
| Output Type | Transistor |
| Voltage - Output (Max) | 35V |
| Current - Output / Channel | 8mA |
| Voltage - Forward (Vf) (Typ) | 1.7V |
| Current - DC Forward (If) (Max) | 25 mA |
| Vce Saturation (Max) | - |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-SOIC (0.173", 4.40mm Width), 5 Leads |
| Supplier Device Package | 5-SOP |
