| Name | Value |
|---|---|
| Product Status | Obsolete |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 900 V |
| Current - Continuous Drain (Id) @ 25°C | 28A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 260mOhm @ 14A, 10V |
| Vgs(th) (Max) @ Id | 4.5V @ 150µA |
| Gate Charge (Qg) (Max) @ Vgs | 490 nC @ 10 V |
| Vgs (Max) | ±30V |
| Input Capacitance (Ciss) (Max) @ Vds | 12000 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 500W (Tc) |
| Operating Temperature | -65°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Supplier Device Package | ISOTOP® |
| Package / Case | ISOTOP |
