| Name | Value |
|---|---|
| Product Status | Active |
| Type | Plug, Female Sockets |
| Number of Positions | 5 (Mate), 10 (Input) |
| Positions Per Level | 5 (Mate), 10 (Input) |
| Number of Levels | 1 (Mate), 2 (Input) |
| Pitch | 0.138" (3.50mm) |
| Header Orientation | - |
| Plug Wire Entry | 180° |
| Termination Style | Screwless - Leg Spring, Push-In Spring |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | 2A |
| Voltage - IEC | 630 V |
| Current - UL | 2 A |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG | 20-26 AWG |
| Wire Gauge or Range - mm² | 0.14-0.5mm² |
| Color | Gray |
| Operating Temperature | -60°C ~ 105°C |
| Contact Mating Finish | Tin |
| Features | Push Button Actuated |
