| Name | Value |
|---|---|
| Product Status | Active |
| Type | Plug, Female Sockets |
| Number of Positions | 8 |
| Positions Per Level | 8 |
| Number of Levels | 1 |
| Pitch | 0.400" (10.16mm) |
| Header Orientation | - |
| Plug Wire Entry | 180° |
| Termination Style | Screw - Clamping Yoke (Tension Sleeve) |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | 78.3A |
| Voltage - IEC | 1 kV |
| Current - UL | 60 A |
| Voltage - UL | 600 V |
| Wire Gauge or Range - AWG | 4-22 AWG |
| Wire Gauge or Range - mm² | 0.2-16mm² |
| Color | Black |
| Operating Temperature | -50°C ~ 130°C |
| Contact Mating Finish | Silver |
| Features | - |
